AMD Ryzen 5 8500G — Ryzen 5 8000-G Series Phoenix (Zen 4) 6-Core 3.5 GHz Socket AM5 65W AMD Radeon 740M Processor - 100-100000931BOX

AMD Ryzen 5 8500G — Ryzen 5 8000-G Series Phoenix (Zen 4) 6-Core 3.5 GHz Socket AM5 65W AMD Radeon 740M Processor - 100-100000931BOX
AMD Ryzen 5 8500G — Ryzen 5 8000-G Series Phoenix (Zen 4) 6-Core 3.5 GHz Socket AM5 65W AMD Radeon 740M Processor - 100-100000931BOX
AMD Ryzen 5 8500G — Ryzen 5 8000-G Series Phoenix (Zen 4) 6-Core 3.5 GHz Socket AM5 65W AMD Radeon 740M Processor - 100-100000931BOX
AMD Ryzen 5 8500G — Ryzen 5 8000-G Series Phoenix (Zen 4) 6-Core 3.5 GHz Socket AM5 65W AMD Radeon 740M Processor - 100-100000931BOX
AMD Ryzen 5 8500G — Ryzen 5 8000-G Series Phoenix (Zen 4) 6-Core 3.5 GHz Socket AM5 65W AMD Radeon 740M Processor - 100-100000931BOX
8,700 EGP
Ex Tax: 8,700 EGP
  • Stock: In Stock
  • Model: 100-100000931BOX

General Specifications
Name: AMD Ryzen™ 5 8500G
Family: Ryzen
Series: Ryzen 8000 Series
Form Factor: Desktops
AMD PRO Technologies: No
Consumer Use: Yes
Regional Availability: Global
Former Codename: Phoenix
Architecture: 2x Zen 4, 4x Zen 4c

CPU Details
Number of CPU Cores: 6
Multithreading (SMT): Yes
Number of Threads: 12
Max. Boost Clock: Up to 5 GHz
Max Zen4c Clock: Up to 3.7 GHz
Base Clock: 3.5 GHz
Zen4 Base Clock: 4.1 GHz
Zen4c Base Clock: 3.3 GHz
L2 Cache: 6 MB
L3 Cache: 16 MB
Default TDP: 65W
AMD Configurable TDP (cTDP): 45-65W
Processor Technology for CPU Cores: TSMC 4nm FinFET
CPU Compute Die (CCD) Size: 137mm²
Package Die Count: 1
AMD EXPO™ Memory Overclocking Technology: Yes
Precision Boost Overdrive: Yes
Curve Optimizer Voltage Offsets: Yes
AMD Ryzen™ Master Support: Yes
CPU Socket: AM5
CPU Boost Technology: Precision Boost 2
Instruction Set: x86-64
Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax): 95°C
Launch Date: January 31, 2024

Connectivity
Native USB 4 (40Gbps) Ports: 2
Native USB 3.2 Gen 2 (10Gbps) Ports: 2
Native USB 2.0 (480Mbps) Ports: 1
PCI Express® Version: PCIe® 4.0
Native PCIe® Lanes (Total/Usable): 14, 10
NVMe Support: Boot, RAID0, RAID1

System Memory
Memory Type: DDR5
Memory Channels: 2
Max. Memory: 256 GB
Memory Subtype: UDIMM
Max Memory Speed:

  • 2x1R: DDR5-5200
  • 2x2R: DDR5-5200
  • 4x1R: DDR5-3600
  • 4x2R: DDR5-3600

Graphics Capabilities
Graphics Model: AMD Radeon™ 740M
Graphics Core Count: 4
Graphics Frequency: 2800 MHz
DirectX® Version: 12
DisplayPort™ Version: 2.1
DisplayPort Extensions: Adaptive-Sync, HDR Metadata, UHBR10
DisplayPort Max Refresh Rates (SDR):

  • 7680x4320 @ 60Hz
  • 3840x2160 @ 240Hz
  • 3440x1440 @ 360Hz
  • 2560x1440 @ 480Hz
  • 1920x1080 @ 600Hz
    DisplayPort Max Refresh Rates (HDR):
  • 7680x4320 @ 60Hz
  • 3840x2160 @ 240Hz
  • 3440x1440 @ 360Hz
  • 2560x1440 @ 480Hz
  • 1920x1080 @ 600Hz
    HDMI® Version: 2.1
    HDCP Version Supported: 2.3
    USB Type-C® DisplayPort™ Alternate Mode: Yes
    Multi-Monitor Support: Yes
    Max Displays: 4
    AMD FreeSync™: Yes
    Wireless Display: Miracast

Video Capabilities
Max Video Encode Bandwidth (SDR):

  • 1080p630 8bpc H.264
  • 1440p373 8bpc H.264
  • 2160p175 8bpc H.264
  • 1080p630 8bpc H.265
  • 1440p373 8bpc H.265
  • 2160p175 8bpc H.265
  • 4320p43 8bpc H.265
  • 1080p864 8/10bpc AV1
  • 1440p513 8/10bpc AV1
  • 2160p240 8/10bpc AV1
  • 4320p60 8/10bpc AV1

Max Video Decode Bandwidth:

  • 1080p60 8bpc MPEG2
  • 1080p60 8bpc VC1
  • 1080p786 8/10bpc VP9
  • 2160p196 8/10bpc VP9
  • 4320p49 8/10bpc VP9
  • 1080p1200 8bpc H.264
  • 2160p300 8bpc H.264
  • 4320p75 8bpc H.264
  • 1080p786 8/10bpc H.265
  • 2160p196 8/10bpc H.265
  • 4320p49 8/10bpc H.265
  • 1080p960 8/10bpc AV1
  • 2160p240 8/10bpc AV1
  • 4320p60 8/10bpc AV1

Additional Features
AMD SmartAccess Memory: Available
AMD Ryzen™ AI: Not Available

Security, Virtualization, and Manageability
AMD Enhanced Virus Protection (NX bit): Yes

Operating System Support
Supported OS:

  • Windows 11 - 64-Bit Edition
  • Windows 10 - 64-Bit Edition
  • RHEL x86 64-Bit
  • Ubuntu x86 64-Bit
