Cooler Master MasterFrame 500 Mesh Mid-Tower – Tempered Glass & Dual 200mm ARGB Fans, 390mm GPU Clearance, 360mm Radiator Support & USB 3.2 Gen 2x2 Type-C (20 Gbps)

Design & Build

• Case Type: Mid Tower
• Color: Silver
• Materials:
  • Front Panel: Mesh
  • Side Panel: Tempered Glass
• Dimensions: 471 × 261 × 544 mm (L × W × H, including protrusions)
• Expansion Slots: 8 standard PCI slots

Compatibility & Layout

• Motherboard Support:
  • Mini-ITX
  • Micro-ATX
  • ATX
  • E-ATX*
  • SSI-CEB*
  • Mini-DTX
• Drive Bays:
  • 2 × 3.5" Drive Bays
  • 2 × 2.5" Drive Bays
• Maximum Component Clearance:
  • CPU Cooler Height: 190 mm
  • GPU Length: 390 mm
  • PSU Length: 235 mm

Cooling & Airflow

• Pre-installed Fans:
  • Front: 2 × 200mm ARGB Fans
  • Rear: 1 × 120mm ARGB Fan
  • Total: 3 ARGB Fans included
• Fan Support:
  • Up to 4 × 140mm fans
  • Up to 4 × 200mm fans
  • Up to 4 × 180mm fans
  • Up to 8 × 120mm fans
• Radiator Support:
  • Front: Up to 360mm
  • Top: Up to 360mm
  • Rear: 120mm
  • Supported sizes: 120mm, 140mm, 240mm, 280mm, 360mm

I/O Panel

• 1 × USB 3.2 Gen 2x2 Type-C (20 Gbps)
• 2 × USB 3.2 Gen 1 Type-A ports
• 1 × 3.5mm Headset Jack (Audio Combo)

Power Supply

• Type: Standard ATX (Not included)
• Maximum Length: 235 mm

Key Features

• Mesh Front Panel: Maximizes airflow for superior thermal performance
• Tempered Glass Side Panel: Showcases your build with a clear view
• Dual 200mm ARGB Fans: Massive front fans provide exceptional airflow and stunning RGB lighting
• High-Speed USB Type-C: USB 3.2 Gen 2x2 port delivers 20Gbps transfer speeds
• E-ATX Support: Accommodates large enthusiast-grade motherboards
• GPU Support Bracket: Integrated support bracket ensures structural integrity for heavy graphics cards
• Extensive Radiator Support: Top and front mounting for up to 360mm AIO liquid coolers
• Generous Clearance: Supports GPUs up to 390mm and CPU coolers up to 190mm

Pro Tip: Optimized Thermal Performance

Warranty

• 1-2 Years Limited Warranty (varies by region)
