Sapphire Pulse AMD Radeon RX 6650XT Gaming Graphics Card — 8GB GDDR6 128-Bit Memory, 2635 MHz Boost Clock, 2048 Stream Processors, RDNA 2 Architecture, HDMI/3*DP Ports

General Specifications

• Architecture: AMD RDNA™ 2

• Engine Clock:

  • Boost Clock: Up to 2635 MHz

  • Game Clock: Up to 2410 MHz

• Stream Processors: 2048

• Infinity Cache: 32MB

• Ray Accelerators: 32

• Memory Size/Bus: 8GB GDDR6

• Memory Clock: 17.5 Gbps Effective

• Displays: Maximum 4 Displays

• Resolution:

  • HDMI™: 7680×4320

  • DisplayPort 1.4: 7680×4320

• Interface: PCI-Express 4.0 x8

Outputs

• 1x HDMI

• 3x DisplayPort

BIOS Support

• UEFI

Game Index

• 1080P

Sapphire Features

• Premium Digital Power Design

• Fuse Protection

• Optimized Composite Heatpipe

• Dual-X Cooling Technology

• Intelligent Fan Control

• Precision Fan Control

• Metal Backplate with Thermal Pad

• TriXX Supported

• TriXX Boost

AMD Features

• AMD RDNA™ 2 Gaming Architecture

• DirectX® 12 Ultimate

• GDDR6 Memory

• Smart Access Memory

• Infinity Cache

• 7nm GPU

• PCI® Express 4.0 Support

• AMD FreeSync™ Technology

• DisplayPort™ 1.4 with DSC

• HDMI™

• Video Streaming up to 8K

• Radeon™ VR Ready Premium

• AMD FidelityFX

• AMD FidelityFX™ Super Resolution (FSR)

• AMD Radeon™ Super Resolution

• Radeon™ Image Sharpening

• Radeon™ Anti-Lag

• Radeon™ Software

• Game Driver Optimizations

Cooler Type

• Dual Fans

Form Factor

• 2 slot, ATX

• Dimension: 240(L) x 119.85(W) x 44.75(H) mm

Power Consumption

• 176W Total Board Power

OS Compatibility

• Linux®, Windows® 7*, Windows® 10, and Windows 11 (64-bit)

\* Does not support all features including but not limited to Hardware Raytracing.

System Requirements

• Minimum 500 Watt Power Supply

• 1 x 8-pin Power Connector

• PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard

• Minimum 8GB of system memory (16GB recommended)
